OQ40-5
Fully automatic quick coupler system that fits all mini excavators between
1-5 t.
Why OQ?
- Change between various work tools within a few seconds!
- Increased versatility and efficiency.
- No oil spills, saving both money and the environment.
- No messy hose couplings.
- Saves the knees and back of the operator when unnecessary jumps in and out of the cab is avoided.
- The OilQuick system makes your excavator and your company more flexible, competitive, and cost effective.
- OilQuick is an advanced quick coupler system for excavators and can be supplied in various models for machines from 1 to 120 tons.
- Can distribute: Hydraulic oil, grease, water and electricity.
OQ40-5
Imperial
Metric
Max. output torque | 40 kNm |
Bucket radius | 500 mm |
Force at bucket edge | 32 kN |
Width | 240 mm |
Weight (approx) | 30 kg |
Quick coupler with 2 parallel hydraulic cylinders | |
Max. working pressure | 35 MPa |
Load-bearing hose break valves | Yes |
Leak-free quick couplers made of steel, OilQuick | ||
Coupling sizes | 3/8" | 1/2" |
Oil flow at 0.3 MPa pressure loss | 40 L/min | 70 L/min |
Max. continuous working pressure | 35 Mpa | 35 35 Mpa |
No. of couplings | 2 | 2 |
Max. output torque | 29,500 Lb-ft |
Bucket radius | 19.7" |
Force at bucket edge | 7,190 Lb-ft |
Width | 9.4" |
Weight (approx) | 66 Lbs |
Quick coupler with 2 parallel hydraulic cylinders | |
Max. working pressure | 5,080 Psi |
Load-bearing hose break valves | Yes |
Leak-free quick couplers made of steel, OilQuick | ||
Coupling sizes | 3/8" | 1/2" |
Oil flow at 0.3 MPa pressure loss | 11 gal/min | 18 gal/min |
Max. continuous working pressure | 5,080 Psi | 5,080 Psi |
No. of couplings | 2 | 2 |
OQ40-5
Imperial
Metric
Attachment frame for mechanical tools without coupling ramp | ||||
Inside width | 240 mm | |||
Pin distance | 300 mm | |||
Pin diameter | 40 mm | |||
Weight (approx.) | 15 kg |
Attachment frame for hydraulic tools with coupling ramp | |
Inside width | 240 mm |
Pin distance | 300 mm |
Pin diameter | 40 mm |
Weight (approx.) | 26 kg |
Hydraulic tool adapter plate with coupling ramp | |
Inside width | 241 mm |
Pin distance | 300 mm |
Pin diameter | 40 mm |
Weight (approx.) | 50 kg |
Attachment frame for mechanical tools without coupling ramp | ||||
Inside width | 9.44" | |||
Pin distance | 11.8" | |||
Pin diameter | 1.6" | |||
Weight (approx.) | 33 Lbs |
Attachment frame for hydraulic tools with coupling ramp | |
Inside width | 9.44" |
Pin distance | 11.8" |
Pin diameter | 1.6" |
Weight (approx.) | 57.3 Lbs |
Hydraulic tool adapter plate with coupling ramp | |
Inside width | 9.5" |
Pin distance | 11.8" |
Pin diameter | 1.6" |
Weight (approx.) | 110 Lbs |
